Let’s create an Interactive Glass Thermometer using HTML, CSS, and JavaScript with GSAP to deliver a smooth and realistic temperature control experience. This project focuses on visual polish, fluid interactions, and real time feedback, making the thermometer feel alive and responsive.
We’ll use:
- HTML : To structure the thermometer layout, SVG distortion filters, temperature track, scale markings, draggable knob, and live temperature readout.
- CSS : To design a modern glassmorphism interface using blur effects, gradients, glowing plasma mercury, smooth transitions, responsive sizing, and subtle noise textures for a realistic glass feel.
- JavaScript (GSAP + Draggable) : To handle knob dragging, map vertical movement to temperature values, animate mercury height, smoothly transition glow colors, update status text, highlight nearby scale values, and generate animated snow particles when the temperature drops below a threshold.
This project is ideal for learning advanced front end animation techniques, interactive UI design, and state driven visual updates. By combining SVG filters, GSAP animations, and dynamic CSS styling, you can build a highly polished, real world component that demonstrates strong visual storytelling, smooth user interaction, and clean, maintainable code.
HTML :
This HTML builds a glass-style thermometer UI where SVG filters create a moving distortion effect for realistic glass and cold visuals, the main layout shows a temperature track with mercury, a draggable knob, scale, and live temperature text, and external CSS handles styling while GSAP and Draggable power smooth animations and user interaction controlled by script.js.
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<title>Glass Thermometer | @coding.stella</title>
<link rel="stylesheet" href="./style.css">
</head>
<body>
<!-- Snow appears when the temperature drops below 40°F. -->
<svg style="position:absolute; width:0; height:0;">
<defs>
<filter id="turbulent-displace" colorInterpolationFilters="sRGB" x="-20%" y="-20%" width="140%" height="140%">
<feTurbulence type="turbulence" baseFrequency="0.02" numOctaves="10" result="noise1" seed="1" />
<feOffset in="noise1" dx="0" dy="0" result="offsetNoise1">
<animate attributeName="dy" values="700; 0" dur="6s" repeatCount="indefinite" calcMode="linear" />
</feOffset>
<feTurbulence type="turbulence" baseFrequency="0.02" numOctaves="10" result="noise2" seed="1" />
<feOffset in="noise2" dx="0" dy="0" result="offsetNoise2">
<animate attributeName="dy" values="0; -700" dur="6s" repeatCount="indefinite" calcMode="linear" />
</feOffset>
<feTurbulence type="turbulence" baseFrequency="0.02" numOctaves="10" result="noise3" seed="2" />
<feOffset in="noise3" dx="0" dy="0" result="offsetNoise3">
<animate attributeName="dx" values="490; 0" dur="6s" repeatCount="indefinite" calcMode="linear" />
</feOffset>
<feTurbulence type="turbulence" baseFrequency="0.02" numOctaves="10" result="noise4" seed="2" />
<feOffset in="noise4" dx="0" dy="0" result="offsetNoise4">
<animate attributeName="dx" values="0; -490" dur="6s" repeatCount="indefinite" calcMode="linear" />
</feOffset>
<feComposite in="offsetNoise1" in2="offsetNoise2" result="part1" />
<feComposite in="offsetNoise3" in2="offsetNoise4" result="part2" />
<feBlend in="part1" in2="part2" mode="color-dodge" result="combinedNoise" />
<feDisplacementMap in="SourceGraphic" in2="combinedNoise" scale="30" xChannelSelector="R"
yChannelSelector="B" />
</filter>
</defs>
</svg>
<div id="app">
<div class="thermostat-ui">
<div class="thermostat glass-panel">
<div class="thermostat-inner">
<div class="glass-noise"></div>
<div class="scale-container" id="scaleContainer"></div>
<div class="track" id="track">
<div class="mercury" id="mercury"></div>
</div>
<div class="knob-zone">
<div class="knob" id="knob"></div>
</div>
</div>
</div>
<div class="temp-readout">
<div class="temp-value" id="tempValue">70°</div>
<div class="temp-label">CURRENT TEMP</div>
<div class="status-text" id="statusText">Comfortable</div>
</div>
</div>
</div>
<div class="particles-container" id="uiParticles"></div>
<script src='https://cdnjs.cloudflare.com/ajax/libs/gsap/3.12.2/gsap.min.js'></script>
<script src='https://cdnjs.cloudflare.com/ajax/libs/gsap/3.12.2/Draggable.min.js'></script>
<script src="./script.js"></script>
</body>
</html>
CSS :
This CSS styles a glassmorphism thermometer UI by defining glow colors and glass effects, centering the layout, creating a blurred glass body, adding a textured track with glowing animated mercury, a draggable knob, scale marks, and a live temperature readout, while filters, gradients, shadows, and keyframe animations give it a realistic electric plasma and frosted glass look with responsive tweaks for small screens.
:root {
--glass-bg: rgba(10, 10, 10, 0.7);
--glass-border: rgba(255, 255, 255, 0.08);
--glow-color: #00a2fa;
}
/* Global reset */
* {
box-sizing: border-box;
}
html,
body {
margin: 0;
padding: 0;
height: 100vh;
background: #000;
color: #fff;
overflow: hidden;
font-family: "Inter", system-ui, sans-serif;
}
#app {
height: 100vh;
display: flex;
align-items: center;
justify-content: center;
}
/* Glass body */
.glass-panel {
background: var(--glass-bg);
backdrop-filter: blur(20px) saturate(180%);
-webkit-backdrop-filter: blur(20px) saturate(180%);
border: 1px solid var(--glass-border);
box-shadow: 0 8px 32px rgba(0, 0, 0, 0.6);
}
.thermostat-ui {
position: relative;
display: flex;
flex-direction: column;
align-items: center;
gap: 28px;
}
/* Main body */
.thermostat {
position: relative;
width: 150px;
height: 520px;
border-radius: 999px;
overflow: visible;
}
.thermostat-inner {
position: relative;
width: 100%;
height: 100%;
border-radius: inherit;
overflow: visible;
}
.thermostat-inner::before {
content: "";
position: absolute;
inset: 0;
border-radius: inherit;
border: 1px solid rgba(255, 255, 255, 0.1);
mix-blend-mode: soft-light;
pointer-events: none;
}
/* Texture */
.glass-noise {
position: absolute;
inset: 0;
border-radius: inherit;
opacity: 0.08;
mix-blend-mode: overlay;
pointer-events: none;
}
/* Track */
.track {
position: absolute;
top: 46px;
bottom: 46px;
left: 50%;
transform: translateX(-50%);
width: 42px;
border-radius: 999px;
background:
radial-gradient(circle at 50% 0%, rgba(255, 255, 255, 0.35) 0, transparent 55%),
radial-gradient(circle at 50% 100%, rgba(0, 0, 0, 1) 0, rgba(0, 0, 0, 0.9) 70%),
linear-gradient(180deg, rgba(255, 255, 255, 0.04), rgba(0, 0, 0, 0.8));
background-blend-mode: screen, normal, soft-light;
box-shadow: inset 0 0 18px rgba(0, 0, 0, 1), 0 0 18px rgba(0, 0, 0, 0.8);
overflow: hidden;
}
/* Electric plasma fill */
.mercury {
position: absolute;
bottom: 0;
left: -45%;
width: 190%;
height: 0%;
background: var(--glow-color);
filter: url(#turbulent-displace);
mix-blend-mode: screen;
box-shadow: 0 0 45px var(--glow-color), 0 0 90px var(--glow-color);
transition: height 0.12s linear, box-shadow 0.3s ease, background 0.25s ease;
opacity: 0.95;
}
/* Flowing current over plasma */
.mercury::before,
.mercury::after {
content: "";
position: absolute;
inset: 0;
border-radius: inherit;
filter: blur(6px);
background: radial-gradient(circle at 50% 50%, rgba(255, 255, 255, 0.3), transparent 90%);
mix-blend-mode: color-dodge;
opacity: 0.25;
animation: pulseElectric 3s infinite ease-in-out alternate;
}
.mercury::after {
filter: blur(16px);
opacity: 0.18;
animation-delay: 1.5s;
}
@keyframes pulseElectric {
0% {
opacity: 0.15;
transform: scaleY(1);
}
100% {
opacity: 0.35;
transform: scaleY(1.05);
}
}
/* Knob */
.knob-zone {
position: absolute;
top: 46px;
bottom: 46px;
left: 0;
right: 0;
pointer-events: none;
}
.knob {
position: absolute;
left: 50%;
transform: translate(-50%, -50%);
width: 72px;
height: 72px;
border-radius: 999px;
background: rgba(10, 10, 10, 0.7);
backdrop-filter: blur(12px) saturate(260%) brightness(1.25);
-webkit-backdrop-filter: blur(12px) saturate(260%) brightness(1.25);
border: 1px solid rgba(255, 255, 255, 0.14);
box-shadow: inset 0 1px 18px rgba(255, 255, 255, 0.15), 0 8px 26px rgba(0, 0, 0, 0.9);
cursor: grab;
pointer-events: auto;
transition: box-shadow 0.2s ease, transform 0.15s ease;
}
.knob:active {
transform: translate(-50%, -50%) scale(1.05);
}
/* Scale container and marks */
.scale-container {
position: absolute;
top: 46px;
bottom: 46px;
left: -90px;
width: 80px;
pointer-events: none;
}
.scale-mark {
position: absolute;
right: 0;
font-size: 14px;
color: rgba(255, 255, 255, 0.35);
font-weight: 500;
display: flex;
align-items: center;
gap: 6px;
transform-origin: right center;
transition: all 0.1s ease;
}
.tick {
height: 2px;
background: rgba(255, 255, 255, 0.4);
border-radius: 2px;
flex-shrink: 0;
}
/* Temperature readout */
.temp-readout {
text-align: center;
}
.temp-value {
font-size: 5.2rem;
font-weight: 700;
text-shadow: 0 0 48px var(--glow-color);
color: var(--glow-color);
}
.temp-label {
font-size: 0.9rem;
text-transform: uppercase;
letter-spacing: 0.34em;
opacity: 0.7;
margin-top: 10px;
}
.status-text {
margin-top: 8px;
font-size: 1.1rem;
text-transform: uppercase;
letter-spacing: 0.22em;
color: var(--glow-color);
opacity: 0.95;
}
/* More Prominent Snow Particles - full canvas */
.particles-container {
position: fixed;
inset: 0;
pointer-events: none;
z-index: 0;
overflow: hidden;
}
/* Responsive tweak */
@media (max-width: 480px) {
.thermostat {
transform: scale(0.9);
}
}
#app {
z-index: 10;
position: relative;
}
.thermostat-ui,
.thermostat {
z-index: 10;
position: relative;
}
.particles-container {
z-index: 1;
}
/* snow stays behind */
JavaScript:
This JavaScript controls the interactive thermometer by mapping knob drag position to temperature, smoothly updating the mercury height, color gradient, scale highlights, and status text using GSAP, while also changing the glow theme and spawning animated snow particles when the temperature drops below a set threshold, with everything recalculated on load, drag, and resize for a smooth realistic effect.
const CONFIG = {
minTemp: 20,
maxTemp: 110,
defaultTemp: 70,
gradientColors: ["#00eaff", "#0099ff", "#00ff73", "#ffdd00", "#ff8800", "#ff0044"],
gradientStops: [0, 0.25, 0.5, 0.7, 0.85, 1],
thresholds: { snow: 40 }
};
const els = {
track: document.getElementById("track"),
mercury: document.getElementById("mercury"),
knob: document.getElementById("knob"),
scaleContainer: document.getElementById("scaleContainer"),
tempValue: document.getElementById("tempValue"),
statusText: document.getElementById("statusText"),
uiParticles: document.getElementById("uiParticles"),
root: document.documentElement
};
let currentTemp = CONFIG.defaultTemp;
let trackHeight = 0, knobBounds = { minY: 0, maxY: 0 }, scaleItems = [], colorMap;
let snowParticleIntervalId = null;
// linear interpolation helper
const lerp = (a, b, t) => a + (b - a) * t;
function createColorMap() {
const stops = CONFIG.gradientStops;
const colors = CONFIG.gradientColors.map(c => gsap.utils.splitColor(c));
return t => {
t = Math.max(0, Math.min(1, t));
for (let i = 0; i < stops.length - 1; i++) {
const s0 = stops[i], s1 = stops[i + 1];
if (t >= s0 && t <= s1) {
const n = (t - s0) / (s1 - s0);
const c0 = colors[i], c1 = colors[i + 1];
return `rgb(${Math.round(lerp(c0[0], c1[0], n))},${Math.round(lerp(c0[1], c1[1], n))},${Math.round(lerp(c0[2], c1[2], n))})`;
}
}
};
}
function buildScale() {
els.scaleContainer.innerHTML = "";
scaleItems = [];
const min = CONFIG.minTemp, max = CONFIG.maxTemp, range = max - min;
const rect = els.track.getBoundingClientRect();
const trackH = rect.height;
for (let t = min; t <= max; t += 2) {
const el = document.createElement("div");
el.className = "scale-mark";
const tick = document.createElement("div");
tick.className = "tick";
if (t % 10 === 0) tick.style.width = "18px";
else if (t % 5 === 0) tick.style.width = "12px";
else tick.style.width = "6px";
const y = (1 - (t - min) / range) * (trackH - 1);
el.style.top = `${y}px`;
if (t % 10 === 0) el.innerHTML = `${t}<div class="tick"></div>`;
el.appendChild(tick);
el.dataset.temp = t;
els.scaleContainer.appendChild(el);
scaleItems.push(el);
}
}
function updateScaleVisuals(knobY) {
scaleItems.forEach(el => {
const rect = els.track.getBoundingClientRect();
const elY = parseFloat(el.style.top);
const dist = Math.abs(knobY - elY), maxDist = 70;
if (dist < maxDist) {
const p = 1 - dist / maxDist;
gsap.set(el, {
scale: 1 + p * 0.8,
opacity: 0.6 + p * 0.6,
color: "#fff",
textShadow: "0 0 8px var(--glow-color)"
});
} else {
gsap.set(el, {
scale: 1,
opacity: 0.3,
color: "rgba(255,255,255,0.35)",
textShadow: "none"
});
}
});
}
function updateStatusText(t) {
let txt = "";
if (t < 32) txt = "Freezing";
else if (t < 55) txt = "Cold";
else if (t < 66) txt = "Cool";
else if (t <= 74) txt = "Comfortable";
else if (t < 85) txt = "Warm";
else if (t < 95) txt = "Hot";
else txt = "Extreme";
els.statusText.textContent = txt;
}
function applyColorTheme(color) {
els.root.style.setProperty("--glow-color", color);
els.tempValue.style.color = color;
els.statusText.style.color = color;
els.mercury.style.boxShadow = `0 0 40px ${color}, 0 0 80px ${color}`;
}
function updateSystemFromY(yPos) {
yPos = Math.max(knobBounds.minY, Math.min(knobBounds.maxY, yPos));
const pct = 1 - yPos / trackHeight;
const temp = CONFIG.minTemp + pct * (CONFIG.maxTemp - CONFIG.minTemp);
currentTemp = Math.round(temp);
const norm = (currentTemp - CONFIG.minTemp) / (CONFIG.maxTemp - CONFIG.minTemp);
const color = colorMap(norm);
els.tempValue.textContent = currentTemp + "°";
els.mercury.style.height = pct * 100 + "%";
applyColorTheme(color);
updateStatusText(currentTemp);
updateScaleVisuals(yPos);
updateSnowParticles(currentTemp);
}
function initLayout() {
const rect = els.track.getBoundingClientRect();
trackHeight = rect.height;
knobBounds = { minY: 0, maxY: trackHeight };
buildScale();
const norm = (CONFIG.defaultTemp - CONFIG.minTemp) / (CONFIG.maxTemp - CONFIG.minTemp);
const startY = trackHeight * (1 - norm);
gsap.set(els.knob, { y: startY });
updateSystemFromY(startY);
}
function initDrag() {
Draggable.create(els.knob, {
type: "y",
bounds: { minY: knobBounds.minY, maxY: knobBounds.maxY },
inertia: true,
onDrag() { updateSystemFromY(this.y); },
onThrowUpdate() { updateSystemFromY(this.y); }
});
}
/* Improved Snow Particles with more prominence and random fall */
const minSnowSpawnInterval = 1.2;
const maxSnowSpawnInterval = 5;
const minSnowFallDuration = 4;
const maxSnowFallDuration = 7;
function createSnowParticle() {
const p = document.createElement("div");
p.className = "particle";
els.uiParticles.appendChild(p);
const vw = window.innerWidth, vh = window.innerHeight;
const size = Math.random() * 12 + 7;
const baseOpacity = 0.9 + Math.random() * 0.1;
const blurVal = Math.random() * 1.6 + 0.9;
p.style.width = p.style.height = size + "px";
p.style.borderRadius = "50%";
p.style.background = `radial-gradient(circle, rgba(255,255,255,${baseOpacity}) 0%, rgba(255,255,255,${baseOpacity * 0.9}) 70%, transparent 100%)`;
p.style.filter = `blur(${blurVal}px)`; // +30% brightness
p.style.boxShadow = "0 0 24px rgba(255,255,255,0.95)"; // 30% bigger glow
// ALWAYS spawn ABOVE viewport
const startX = Math.random() * vw;
const startY = -50 - Math.random() * 150; // -50 to -200px
gsap.set(p, { x: startX, y: startY, opacity: 0, scale: 0.6 });
const swayX = 80 + Math.random() * 60;
const fallDuration = getSnowFallDuration(currentTemp);
gsap.timeline({ onComplete: () => p.remove() })
.to(p, { opacity: 1, scale: 1, duration: 0.7, ease: "power2.out" })
.to(p, {
y: vh + 80,
x: "+=" + (Math.random() * swayX - swayX / 2),
rotation: Math.random() * 180,
opacity: 0,
duration: fallDuration,
ease: "none"
}, 0)
.to(p, {
x: "+=" + (Math.random() * 40 - 20),
yoyo: true,
repeat: 1,
duration: 2 + Math.random() * 3,
ease: "sine.inOut"
}, 0.2);
}
function getSnowFallDuration(temp) {
const clampedTemp = Math.max(20, Math.min(temp, 40));
const requiredPct = (40 - clampedTemp) / 20;
return lerp(maxSnowFallDuration, maxSnowFallDuration * 0.55, requiredPct); // 30% faster
}
function getSnowSpawnInterval(temp) {
const clampedTemp = Math.max(20, Math.min(temp, 40));
const requiredPct = (40 - clampedTemp) / 20;
return lerp(maxSnowSpawnInterval, maxSnowSpawnInterval * 0.45, requiredPct); // 55% more snow
}
function updateSnowParticles(temp) {
if (temp > CONFIG.thresholds.snow) {
// Stop snow if above threshold
if (snowParticleIntervalId !== null) {
clearInterval(snowParticleIntervalId);
snowParticleIntervalId = null;
}
els.uiParticles.innerHTML = "";
return;
}
if (snowParticleIntervalId !== null) clearInterval(snowParticleIntervalId);
// Spawn immediately on threshold crossing
createSnowParticle();
const spawnInterval = getSnowSpawnInterval(temp) * 100; // convert to ms scaled
snowParticleIntervalId = setInterval(() => {
createSnowParticle();
}, spawnInterval);
}
window.addEventListener("load", () => {
colorMap = createColorMap();
initLayout();
initDrag();
updateSnowParticles(currentTemp);
});
window.addEventListener("resize", () => {
initLayout();
updateSnowParticles(currentTemp);
});
By building this project, you learn how to turn static UI into an immersive experience using motion, visual feedback, and user interaction. It demonstrates how thoughtful animations and dynamic effects can elevate simple components into engaging, production ready interfaces suitable for modern web applications.
If your project has problems, don’t worry. Just click to download the source code and face your coding challenges with excitement. Have fun coding!
